Description
2005-2007 Ford F250-F350 4wd 4in. Radius Arm Suspension Lift Kit| 3in. rear block| Diesel engine Non Overload – Fox 2.0 Performance Series Shocks.
Improve the ride on your 2005-2007 Ford F250 and F350 Super Duty diesel truck with this 4-inch radius arm lift kit from BDS Suspension. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35″ tires.
Up front the lift kit includes diesel-specific Pro-Ride coil springs, heavy-duty replacement radius arms, forged drop pitman arm and track bar bracket for steering correction, sway bar relocation, brake line brackets and precision tuned nitrogen charged shocks.
In the rear the base kit utilizes a high-strength lift block, u-bolt flip kit for max ground clearance, brake line brackets and a matching set of NX2 Nitro or FOX Performance shocks.
HD Radius Arms
In place of the factory stamped steel radius arms BDS supplies a pair of high-strength tubular radius arms. These arms mount into the factory location and offer caster adjustment for a wide range of lift heights along with an OE-style rubber bushing at the frame mount for smooth, quiet, service-free operation.
Pro-Ride Coil Springs
A pair of full-length, diesel-specific, Pro-Ride coil springs are supplied to provide the correct lift height and smooth, predictable ride across various terrains.
Steering Correction
To optimize steering geometry once lifted, a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle.
Features & Benefits
- Easy, 100% Bolt-on installation
- Pro-Ride dual rate coil springs provide a remarkable ride through any terrain
- Heavy duty tubular steel radius arms that correct caster while maximizing ground clearance
- Track bar relocation bracket and pitman arm maintain proper steering angles for improved handling
- Fabricated steel blocks provide level stance from front to rear
- Standard NX2 Nitro shocks with vehicle-specific valving for better control
- Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road
Recommended Tires & Wheels
(Trimming may be required)
- 35 x 12.5 with 18 x 9 and 4.5 in. Backspace
- 35 x 12.5 with 20 x 9 and 4.5 in. Backspace
Rear Lift Option
Block Kit
- Determine if your truck was manufactured with or without top-mounted overload springs on the rear leaf springs.
- Blocks made of steel for high strength.
- Designed to provide correct pinion angles.
Leaf Springs
- Eliminates any need for a lift block.
- Reduces axle wrap and creates a more controlled and stable feel.
- Multi-leaf progressive design for a smooth ride.
- Maintains factory payload weight ratings.
Shock Option
NX2 Nitro Series
- Nitrogen-charged
- Twin-tube design
- 10-stage velocity-sensitive valving
- Dual-welded ends for increased strength
- 1-3/8-inch high-flow piston
- Self-lubricating seals
- Silver powder coat finish
FOX 2.0 Performance Series
- 2-inch Impact extruded aluminum body
- Internal floating piston (IFP) monotube design
- CNC machined 6061-T6 aluminum mounting ends
- Massive 5/8-inch hard chrome plated heat-treated alloy steel shaft
- Race-developed high-flow piston design
- Application-specific valving to maximize performance
- Long-lasting clear anodized finish
Important Information
- These trucks were manufactured with and without top-mounted overload springs on the rear leaf springs. A top-mounted overload is an extra leaf separate from the pack that is set above the main leaf. You will need to identify which you have before ordering.
- If your vehicle is equipped with a carrier bearing, you will need to order 123402 in the accessories section.
More Info
- Front Lift Method : Coil Spring
- Rear Lift Method : Block
- Shocks Included : Yes
- Front Lift Height : 4″
- Rear Lift Height : 3″
- Est. Install Time : 8 hrs.
- Difficulty Level : Moderate
- Specialty Tools Needed : Pitman Arm Puller
Installation Guide 1
Installation Guide 2
Installation Guide 3
KIT COMPONENT LIST
| 0 | BDS1931FS | Block Kit Without Factory Overload / FOX 2.0 Performance Series | |
|---|---|---|---|
| 1 | BDS013329 | 1999-2007 Ford F250/F350 Rear Box Kit w/o overload | |
| 1 | BDS013431 | 2005-2007 Ford F250/F350 4″ Radius Arm Front Box Kit | |
| 1 | BDS123251 | 2005-2022 Ford F250/F350 Radius Arm Kit, Pair | |
| 1 | BDS033411 | 2005-2023 Ford F250/F350 Superduty 4″ Coil Kit – Diesel | |
| 1 | BDS85415 | Steering Stab 23.9 x 14.3 – EB1/EB1 | |
| 2 | FOX98224700 | Fox 2.0 Shock 25.65 x 16.05 x 2- S50/EB1 | |
| 2 | FOX98224760 | Fox 2.0 Shock 33.85 x 20.75 x 2- EB1/EB1 |
Specifications:
| Description_ASC | These trucks were manufactured with and without top-mounted overload springs on the rear leaf springs. A top-mounted overload is an extra leaf separate from the pack that is set above the main leaf. You will need to identify which you have before ordering. |
| Description_ASC | If your vehicle is equipped with a carrier bearing you will need to order 123402 in the accessories section. |
| Description_DES | 2005-2007 Ford F250-F350 4wd 4in. Radius Arm Lift Kit| Diesel Non Overload |
| Description_EXT | 2005-2007 Ford F250-F350 4wd 4in. Radius Arm Suspension Lift Kit| 3in. rear block| Diesel engine Non Overload – Fox 2.0 Performance Series Shocks |
| Description_FAB | Easy 100% Bolt-on installation |
| Description_FAB | Pro-Ride dual rate coil springs provide a remarkable ride through any terrain |
| Description_FAB | Heavy duty tubular steel radius arms that correct caster while maximizing ground clearance |
| Description_FAB | Track bar relocation bracket and pitman arm maintain proper steering angles for improved handling |
| Description_FAB | Fabricated steel blocks provide level stance from front to rear |
| Description_FAB | Standard NX2 Nitro shocks with vehicle-specific valving for better control |
| Description_FAB | Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road |
| Description_MKT | Improve the ride on your 2005-2007 Ford F250 and F350 Super Duty diesel truck with this 4-inch radius arm lift kit from BDS Suspension. Designed to improve stance performance and capability this kit includes everything necessary to set your truck up right with clearance for up to 35″ tires. |
| Description_MKT | To optimize steering geometry once lifted a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle. |
| Description_MKT | Up front the lift kit includes diesel-specific Pro-Ride coil springs heavy-duty replacement radius arms forged drop pitman arm and track bar bracket for steering correction sway bar relocation brake line brackets and precision tuned nitrogen charged shocks. |
| Description_MKT | In the rear the base kit utilizes a high-strength lift block u-bolt flip kit for max ground clearance brake line brackets and a matching set of NX2 Nitro or FOX Performance shocks. |
| Description_MKT | HD Radius Arms |
| Description_MKT | In place of the factory stamped steel radius arms BDS supplies a pair of high-strength tubular radius arms. These arms mount into the factory location and offer caster adjustment for a wide range of lift heights along with an OE-style rubber bushing at the frame mount for smooth quiet service-free operation. |
| Description_MKT | Pro-Ride Coil Springs |
| Description_MKT | A pair of full-length diesel-specific Pro-Ride coil springs are supplied to provide the correct lift height and smooth predictable ride across various terrains. |
| Description_MKT | Steering Correction |
| Description_SHO | Suspension lift kit |
| Description_DEF | Suspension Lift Kit |
